The MS series is a pilot-scale dispersion and mixing equipment. It adopts a bearingless design to achieve quiet operation and zero pollution. It fully complies with GMP standards and is suitable for scenarios with high hygiene requirements.
The MS series is a pilot-scale dispersion and mixing equipment, employing a single-point torque transmission system and a bearingless design. A high-speed motor ensures stable speed, and it comes standard with frequency conversion speed control and speed display. Its quiet, temperature-rise-free, and pollution-free design, along with electric lifting, complies with GMP regulations. The product is suitable for dispersing, emulsifying, homogenizing, and mixing materials that are corrosive, require hygiene standards, or are temperature-sensitive.
| Order # | 6411341 | 6412381 |
| Model | MS10 | MS20 |
| Motor power | 550W | 1500W |
| Power supply | 220V，50Hz | 220V，50Hz |
| Protection grade for motor hood | IP54 | IP54 |
| Speed range | 600-6000rpm | 600-3000rpm |
| Speed display | Digital display | Digital display |
| Speed control | Frequency control | Frequency control |
| Working capacity(H2O) | 1-10L | 3-15L |
| Standard dispersing agitator | High shear agitator | High shear agitator |
| Maximum line speed | 12m/s | 10m/s |
| Medium-contact material | SS316L | SS316L |
| Inverter | Standard | Standard |
| Electric control box | Standard | Standard |
| Electric control box material | SS304 | SS304 |
| Work frame | Electric lifting stand | Electric lifting stand |
| Work frame material | SS304 | SS304 |
| Sound | 85 dB(A) | 85 dB(A) |
| Weight | 44kg | 65kg |
| Overall dimensions | 463×575×780mm | 463×575×780mm |
| Package | Wooden case | Wooden case |
