PDS
Description：PDS is a self R&D automatic powder mixture system. Manages the dynamic balance of the system and maintains powder and liquid mixing process for many continuous mixing materials, with excellent stability and highly efficient batch production.
Advantage：Powder / liquid ratio, feeding, batch mixing of powder / liquid, stable batch quality, full automatic control, reliable CIP.
System Parameter
Flow rate : 10~20 m³/h
Powder sucking rate:
200~350 kg/min (Whey powder)
180~300 kg/min (Sugar)
60~120 kg/min (CMC)
Applications: Milk powder, CMC powder, Whey powder, Sugar, Cereal flour, TiO2, Titanium Dioxide, Betonies, Nano Materials, etc.
Remarks
- The maximum working capacities in above table are based on a water medium.
- The powder suction rate depends on the powder characteristics (such as particle size, swell ability and liquidity, etc.). Please provide samples if uncertain or carry out experiments into appropriate model selection;
- For special working conditions, please provide detailed data to FLUKO engineers to design a custom solutions.
- FLUKO reserves the right to change specifications without announcement.
